SilverStone Kublai KL06 Micro-ATX Chassis Review



/ 2 years ago

Next Page »

Introduction


Silverstone Kublai Chassis

Silverstone is one of the greatest and most established names in the chassis industry, in fact, they’re not exactly lacking in other parts of the market either, with extensive product ranges that cater to power supplies, cooling and much more. Silverstone have a lot of technical knowledge when it comes to what makes a great system and you can see that knowledge being put to great use across their entire range; something we hope to see once again in our latest review.

Today I have the latest entry in the Kublai series and this one is particularly special, as it is the first Micro-ATX form factor product in that range; no doubt to address the increased system capacities required by many of today’s high-end components, such as RAID arrays and long graphics cards.

“Being the first Micro-ATX chassis in the Kublai series, a line of cases famed for layout efficiency with classic styling, the KL06 fills the role perfectly. Equipped with dual 120mm quiet fans for cooling multiple drives and high-end components, it retains SilverStones’ signature positive pressure design for effective dust prevention.” – SilverStone

The chassis caters well to modern hardware, dropping support for lots of 3.5″ drives, favoring a setup for 8 x 2.5″ drives and just a single 3.5″ drive on the interior. Storage bays are removable to make way for water cooling, there’s room for a large graphics card, high-end PSU and a whole lot more; so let’s get right to it and take a closer look at what the KL06 has to offer!

Kublai Chassis Specifications

The Kublai is a fairly simple looking chassis, but none the less, one that is very nicely designed. The left side panel is a solid panel, cut from thick steel that should help greatly reduce unwanted noise and vibrations from your system.

DSC_0723

Another thick panel on the right side of the chassis. Both side panels are mounted with two thumbscrews at the rear, providing you with quick and easy access to the chassis interior.

DSC_0728

The front panel is really nicely designed, with two 5.25″ drive bays at the top and a semi-transparent front panel mesh, behind which you can see the front fans.

DSC_0725

The main I/O panel has all the usual ports and switches while also being another of this years chassis to drop the older USB 2.0 ports entirely.

DSC_0726

The front cover can be easily removed via clip at the bottom, allowing you to easily clean the filter and maintain your fans.

DSC_0727

Around the back, you’ll quickly notice that the motherboard mounting is inverted, with the I/O at the bottom and the PSU mounting at the top. There’s plenty of ventilation here, an optional fan mount at the bottom and a screw on protective cover for the four expansion slot mounts.

DSC_0729

The top panel has a large ventilation section for the PSU air intake.

DSC_0724

It has a magnetic dust filter attached, which is far easier to keep clean than most PSU filters that are located on the underside of the chassis.

DSC_0730

There’s four rubber feet on the bottom of the chassis to help keep it firmly in place, even on hard surfaces.

DSC_0731
